FRS-60 Automatic Tube Filling Sealing Machine 40-60pcs/min



Applying:

This machine is used for filling lotion into the tube and sealing plastic/laninated Alu tube auto.through change the mold our machine can be used for plastic and alu tube both.



Features:



1.Transmission parts enclosed in the platform below the safe, reliable, non-polluting; filling and sealing part of the installation within the platform above a semi-closed static-frame visual plexiglass cover, easy to observe, easy to operate, easy to maintain;



2.Main parts adopt import parts, PLC control system (Siemens), color touch screen dispaly (Siemens), invertor: (Siemens), low electric applicator (Schneider), pneumatic parts (Airtac, Taiwan)



3.Automatically feeding tube into tube holder,with 12 working station,the machine max speed can fill 60pcs tube per min



4.The photoelectric target-aiming working station employs accurate detector and marching type motor,ensuring the tube design at the correct position.



5.Filling nozzle enters tube inside to fill.As it fills it will moves up and prevent material from over flowing and spilling.



Has auto cutting tube tail function when finishing fill the material into the tube.



6.No tube no filling,Sealing temperature adopt (Leister hot air gun) inside heating for the tail of tube and cooling device for out of tube.



7.Automatically printing the character code on the tube bottom.



8.Has overload protection



9. Has accounting and auto stop machine when reach the number



Parameters:



1	Model	FRS-60	FRS-50
2	Voltage	220V/380V 50-60Hz	220V/380V 50-60Hz
3	Productivity	40-60 pcs/min	30-50 pcs/min
4	Filling volume	5-300ml	5-300ml
5	Tube diameter	10-50mm	10-50mm
6	Tube length	50-250mm	50-250mm
7	Max power	3kw	3kw
8	Working station	12	12
9	Water consumption	3-6L/Min	3-6L/Min
10	Machine weight	2100kg	1600kg
11	Dimension(L*W*H)	1900*1800*1200mm	1500*1600*1200mm



Detailed imagines:
